ACA crusher for recycling of plasterboard and production waste

Crusher for recycling of plasterboards and production waste for use in the production of new plasterboards.

The crusher is particularly suited for the crushing of gypsum without creating paper contamination in the final gypsum product. This applies to plasterboards, production waste as well as offcuts from new plasterboards.

Reuse to make new plasterboards

The ACA crusher crushes the plasterboard and separates the gypsum from the paper, which is later removed.

Once the paper has been removed, the gypsum can be used in the production of new plasterboards.

Very economical machine and easy to adjust

The machine is slow-turning which makes it both efficient and economical. And makes it super strong as well.

The size of the plasterboard output can easily be adjusted as desired.

Crush the plasterboard and recycle the gypsum residue

ACA crusher for recycling of faulty production of plasterboards from gypsum manufacturers in 24/7 operation.

The ACA crusher is fitted with a large hopper which is adjusted to the customer’s requirements. The waste can easily be loaded into the hopper with the help of a Digger or from a conveyor belt.

Coarse crusher for plasterboards operating 24/7

The ACA crusher is available in various versions. The crusher can be supplied in standard sizes with 2, 3, 4, 6, 8, or 10 screws depending on the size of the input material and the desired amount of output.

w

Send us an e-mail and we will tell you what makes our crushers so unique!

;
w

Call us now and let us tell you why our bale opener and crushers are unique!

Recycling of plasterboards

The crusher crushes the gypsum and separates it from cardboard and paper in order to use it in the production of new plasterboards.

Effective crusher for crushing of plasterboards

The crusher produces an even flow of output. This makes it much easier to optimise the subsequent screening of the material to suit the rest of the production process.

Hopper for plasterboards to be crushed

Large tailor-made hopper for plasterboard

The large and customized hopper makes sure that the plasterboard easily can be loaded from either a conveyor belt or digger.

Slow-turning crusher for plasterboards

With only 15 RPM and a tourque of 13.000 N the slow-turning crusher will be both economical and efficient – also the amount of dust is limited.

Strong crusher for crushing of plasterboards and gypsum residue

With a weight of between 5 and 20 tonnes, a torque of 13,000 newton metres and reverse operation in the event of excess current, breakdown of the crusher can be avoided, and many years of useful life and safe, reliable 24/7 operation in the company is assured.

Low noise level

As the machine is slow-turning, the noise level is as low as 75 DB when the machine is empty. The only thing you hear is the cooling of the machine.

Cheap in operation

Because the movable parts of the machine do not touch each other, it gives you a long useful life of the parts. The plasterboards are crushed against each other and thereby separating the plasterboards gypsum and the paper for subsequent sorting.

Output: plasterboard and gypsum residue

The ACA crusher’s flexible design makes it easy for the user to regulate the size of the output material by adjusting the rotating knives. The knives are easy to replace.

Crushing of plasterboard without pollution

The crusher is extremely well suited for the crushing of gypsum withoutcreating paper (fiber) contamination in the final gypsum product. This applies to plasterboards, production waste and offcuts from new plasterboards, which can subsequently be used in the production of new plasterboards.

Faulty plasterboards from gypsum manufacturers

w

Ring nu og hør hvorfor vores neddelere er unikke!

All types of plasterboards

The recycling of material plays an increasing role in modern society both from a financial point of view and out of concern for the climate and the environment, as it is uneconomical and unsustainable to only use virgin materials. The use of gypsum in the production of new plasterboards thus presents many advantages, and all types of gypsum can be recycled.

Modern plasterboards are a very broad-spectrum product. In some cases, different molecules and substances may be added to make the plasterboard actively absorb and release heat, which means that the plasterboard can play a role in regulating the indoor temperature in office environments. This type of gypsum can still be recycled, so the more gypsum waste and offcuts that can be collected for recycling, the better.

The crusher separates gypsum, paper and other materials, if any, producing a very pure fraction that is highly suitable for further recycling.

This separation of paper, fibre and pure gypsum determines the degree to which the gypsum output from the crusher can be recycled.

The paper can also be used in the production of new paper, but another option is to send it to an incineration plant, where it will contribute to the production of CO2-neutral electricity and heating.

Screened gypsum ready to be recycled as new plasterboards

After screening of the crushed material you are typically left with three fractions: gypsum, paper and metal.

Gypsum paper after screening

The screening of the gypsum leaves behind large pieces of paper with bits of gypsum attached, which can be recycled later.
